CB 直流充电器-11
|
|
| 型号︰ | CB-10，CB-30，CB- |
| 品牌︰ | 拓朴 |
| 原产地︰ | 中国 |
| 单价︰ | - |
| 最少订量︰ | 100 件 |
|
|
|
|
|
|
|
| 产品规格︰ | CB-10
Input Voltage (V): 230
Rated Working Capacity (w): 100w
Charger Voltage (V): 12 or 24
Effective Charging Current (A):8/5
Class of Insulation: H
Rated Charging Current (A):5/3
Max. Rated reference Capacity (Ah): 92
Min. Rated reference Capacity (Ah): 92
Weight (kg): 5
External Dimension (cm): 26*23*19.7
20ft Container load: 2400
CB-15
Input Voltage (V): 230
Rated Working Capacity (w): 150w
Charger Voltage (V): 12 or 24
Effective Charging Current (A):9/6
Class of Insulation: H
Rated Charging Current (A):6/4
Max. Rated reference Capacity (Ah): 105
Min. Rated reference Capacity (Ah): 25
Weight (kg): 5.2
External Dimension (cm): 26*23*19.7
20ft Container load: 2400
CB-18
Input Voltage (V): 230
Rated Working Capacity (w): 200w
Charger Voltage (V): 12 or 24
Effective Charging Current (A):14/9
Class of Insulation: H
Rated Charging Current (A):8/5
Max. Rated reference Capacity (Ah): 120
Min. Rated reference Capacity (Ah): 25
Weight (kg): 7.2
External Dimension (cm): 26*23*19.7
20ft Container load: 2400
CB-20
Input Voltage (V): 230
Rated Working Capacity (w): 300w
Charger Voltage (V): 12 or 24
Effective Charging Current (A):18/12
Class of Insulation: H
Rated Charging Current (A):12/8
Max. Rated reference Capacity (Ah): 200
Min. Rated reference Capacity (Ah): 60
Weight (kg): 7.4
External Dimension (cm): 26*23*19.7
20ft Container load: 2400
CB-30
Input Voltage (V): 230
Rated Working Capacity (w): 700w
Charger Voltage (V): 12 or 24
Effective Charging Current (A):30
Class of Insulation: H
Rated Charging Current (A):20
Max. Rated reference Capacity (Ah): 250
Min. Rated reference Capacity (Ah): 92
Weight (kg): 9.5
External Dimension (cm): 28.5*23*21
20ft Container load: 2200
CB-40
Input Voltage (V): 230
Rated Working Capacity (w): 800w
Charger Voltage (V): 12 or 24
Effective Charging Current (A):45
Class of Insulation: H
Rated Charging Current (A):25
Max. Rated reference Capacity (Ah): 300
Min. Rated reference Capacity (Ah): 100
Weight (kg): 11
External Dimension (cm): 30.5*29*21.5
20ft Container load: 1500
CB-50
Input Voltage (V): 230
Rated Working Capacity (w): 1000w
Charger Voltage (V): 12 or 24
Effective Charging Current (A):50
Class of Insulation: H
Rated Charging Current (A):30
Max. Rated reference Capacity (Ah): 320
Min. Rated reference Capacity (Ah): 120
Weight (kg): 11.5
External Dimension (cm): 30.5*29*21.5
20ft Container load: 1500 |
| 产品优点︰ | Single-phase, portable battery charger for charging Lead-Acid batteries 12/24v voltage, Protected against over-load and polarity reversal, equipped with ammeter.
Various plug for your choosing
Possibility of use in harsh conditions: IP23C
The high power available means that all application requirements can be satisfied. |
| 主要市场︰ | 全球 |
| 参考单价︰ | 面议 |
| 付款方式︰ | 电汇 |
| 最小订量︰ | 10 |
| 交货日期︰ | 20天 |
| 认可标准︰ | ISO9001,CCC |
|
|
